30L matū matū e pupuhi ana te raima

Model:KGH30D

I hoahoatia me o matea o te kohinga matū, ko te KGh30D he kaiwhakaora matūru e rua rau e pupuhi ana mo te miihini miihini-tere. He pai mo te 25l miihini hanga miihini, penei i te 25l me te 30l matū 30l, ka pai te tiaki me te penapena utu ka taea e koe te whakawhirinaki. Me tuku atu maatau ki a maatau ki te waihanga i to otinga tuuturu i tenei ra!

Rorohiko: 30lTaumaha: 28.5t

Tuku Uiui

Whakaahuatanga Hua Specification Application

Tino pai mo te whakaputa 25L me te 30l matū Paru, ka whakarite tenei miihini i te roa me te utu-utu, te mahi He taonga nui mo tetahi raina whakaputa. Me tana hoahoa matatau me te Pororangi, ko te KWH30D 30L Dr Dr Drum Dr Dr Drum Dr Drum Dr Dr Drum Drum Drumer Side e pupuhi ana i te miihini i te wa e awhina ana i a koe Whakanuihia te whai hua me te whakaiti i nga utu whakahaere. Hoa me matou i tenei ra ki Waihangahia tetahi otinga tuuturu e pa ana ki o hiahia motuhake me te whakanui i to Nga kaha whakatipu.

Nga waahanga me nga painga

Whakanuihia to whakaputanga me to maatau miihini-a-rua-a-ringa e hangai ana, i hangaia mo nga ipu tae atu ki te 30l. Ma te whirihora ngawari (2, 3, e 4 ranei nga huinga upoko-mate), ka pa ki nga ipu iti ki nga ipu 30L me nga papa kirihou, te whakarite i te kounga pai.
He pai mo nga tono penei i a Shampoo, horoi horoi horoi, me nga whakapaipai whakapaipai, ka tukuna e tenei miihini te tere tere i te wa e pupuri ana i te kounga o runga. Ko tana pukenga me te pai o te hoahoa ka awhina i te whakaheke i te aukati me te whakapiki ake i te whakaputanga, te whakarite i te otinga utu e whakanui ana i to hokinga mai ki te haumi.

Specifications

serial number	Material PE、PP、PVC、PA...	High speed movement mode(curved arm)
serial number	Material PE、PP、PVC、PA...	Machine model:KGH30D
Specifications
1	Max container capacity	30L
2	Output(dry Cycle)	450 PC/HR x 2 PC/HR
3	Machine Dimension(L×W×H)	5.8 M x 4.2 M x 3.8 M
4	Machine weight	28.5T
Clamping Unit
1	Clamping force	300 KN
2	Mold platen size(W×H)	630 MM x680 MM
3	Platen openingstroke	450 MM -1000 MM
4	Platen moving stroke	750 MM
5	Max mold size(W×H)	730 MM -680 MM
6	Mold thickness	480 MM -580 MM
Power
1	Servooil pump motor power	22 KW
2	Servo pump displacement	200 L/MIN
3	Blowpressure	0.6 Mpa
4	Air consumption	1.8 M³/MIN
5	Cooling water pressure	0.2 Mpa - 0.3 Mpa
6	Water consumption	180 L/min
7	Average energy consumption	70 KW -80 KW
Extruder unit
1	Screw diameter	100 MM
2	Screw L/D ratio	25 L/D
3	Melting capacit for HDPE	300 Kg/hr
4	Number of heating zone	5 ZONE
5	Screw heating power	20 KW
6	Screw fanpower	0.9 KW
7	Extruder motor power	90 KW
Die head
1	Number of heating sections	3 * 8 ZONE
2	Heating power	6.5 KW
3	Maxdie-pin diameter	220 MM
4	Accumulator capacity	280 MM
5	(PE)Accumulator weight	170 MM
