10L Whakapaipai i te miihini hangai miihini

Model:KGB70A

Ko te KGB70A he kohinga 10L ka whakaemihia te miihini hanga miihini i hangaia mo te max-rita pupuhi pupuhi pupuhi. Hei kaiwhakanao miihini peita wai e arahi ana, ka tukuna e matou nga otinga whakarite hei whakatutuki i nga whakaritenga a te kaihoko. Ehara i te miihini anake mo nga pounamu wai, nga ipu penicines, me te hanga matū matū o ia ra, engari mo nga hua iti engari ko nga hua iti engari. Ka tutuki tenei miihini i nga matea rereke.

Rorohiko: 20LTaumaha: 7.8t

Tuku Uiui

Whakaahuatanga Hua Specification Application

Kgb70 10l te whakaemi i te miihini hangai te miihini he whakatuwhera me te kati Tauira, e whaaia ana e rua te taapiri i nga miihini whakapiri i te raima, te hinu Ko te pehanga tuuturu e mau ana i te papatipu, ko te Cylinder Sylinder i whakamate i te upoko. Te whakahaere pūnaha serdralic serdralic, tere tere tere me te penapena kaha.
Suitetahi atu Suite mo taua mahinga hua hangahanga hoahoa motuhake, ka taea Ko te whakahaere i te ahua me te matotoru he tika ake.

Nga waahanga me nga painga

Ko tenei tauira he whakatuwhera me te kati, me te whakamahi i nga miihini taapiri raima honohono honohono, me te miihini o te hinu totika ka pahemo te pehanga
● Rauemi rokiroki rokiroki
● Te Rahi Rahi 20L
● He pai mo nga pounamu wai, nga ipu penicines, me te kohinga matū o ia ra, me etahi atu.
● Ko te ahuatanga motuhake ko te whakahaere e te punaha servolic hei whakatutuki i te whakautu tere tere me te kaha kaha o te kaha.

Specifications

serial number	Material PE、PP、ABS ...	Mold closing oil cylinder(single cylinder)
serial number	Material PE、PP、ABS ...	Machine model:KGB70A
Specifications
1	Max container capacity	20L
2	Output(dry Cycle)	700 PC/HR
3	Machine Dimension(L×W×H)	4.3 M x1.7 M x3.9 M
4	Machine weight	7.8 T
Clamping Unit
1	Clamping force	130 KN
2	Mold platen size(W×H)	680 MM x 600 MM
3	Platen openingstroke	300 MM - 850 MM
4	Platen moving stroke	370 MM
5	Max mold size(W×H)	460 MM×600 MM
6	Mold thickness	310 MM - 380 MM
Power
1	Servooil pump motor power	11KW
2	Servo pump displacement	80 L/MIN
3	Blowpressure	0.8 Mpa
4	Air consumption	0.7 M²/MIN
5	Cooling water pressure	0.3 Mpa
6	Water consumption	60 L/min
7	Average energy consumption	18 KW-22 KW
Extruder unit
1	Screw diameter	70 MM
2	Screw L/D ratio	24 L/D
3	Melting capacit for HDPE	80 Kg/hr
4	Number of heating zone	3 ZONE
5	Screw heating power	12.6 KW
6	Screw fanpower	0.5 KW
7	Extruder motor power	22 KW
Die head
1	Number of heating sections	5 ZONE
2	Heating power	20 KW
3	Maxdie-pin diameter	180 MM
4	Accumulator capacity	3 L
5	(PE)Accumulator weight	2.25 KG
